Electrical Switch Fuse Module – Localized Overcurrent Protection

The Electrical Switch Fuse Module combines rigorous overcurrent protection with a manual switching device in a single, compact unit. Designed for DIN-rail or block-mount installation, it protects individual circuits by tripping on overloads or short circuits while allowing quick isolation of the circuit for service. Suitable for 120/240V systems, typical ratings range from 10A to 60A (with higher variants available for specific installations). The module accepts compatible fuse cartridges and features a secure handle/lever for safe operation, clear visibility of status, and simple field replacement. Its modular form supports easy expansion within standard electrical panels and distribution boards, helping to meet code requirements for circuit protection and serviceability.

Key Features

• Integrated switch and fuse protection in one compact unit
• Targeted overcurrent protection for individual circuits
• DIN-rail or block-mount installation options
• Voltage rating: commonly 120/240V; current ratings 10A–60A (verify SKU)
• Cartridge fuse compatibility for easy replacement
• Clear operating handle and status indication
• Fast, safe isolation for maintenance or emergencies
• Compact footprint suitable for standard panels and enclosures
• Compliance: UL/CE/CSA or local equivalents (verify for region)

Applications

• Residential service panels and subpanels
• Dedicated circuits (water heaters, HVAC, pool equipment)
• Light commercial distribution boards
• Any installation requiring localized protection with quick isolation

Benefits

• Precise protection minimizes nuisance trips and protects wiring
• Safe, rapid circuit isolation without powering down the entire panel
• Easy to install and service with standard fuse cartridges
• Helps meet electrical codes for circuit protection and maintenance accessibility
